Durable High Density Urethane Tooling Board For Rapid Prototype Modeling

Durable High Density Urethane Tooling Board For Rapid Prototype Modeling

    • Durable High Density Urethane Tooling Board For Rapid Prototype Modeling
  • Durable High Density Urethane Tooling Board For Rapid Prototype Modeling

    Product Details:

    Place of Origin: China
    Brand Name: LH-tool®
    Certification: ISO9001:2008 Standard
    Model Number: MB5112

    Payment & Shipping Terms:

    Minimum Order Quantity: 10 Sheets
    Price: Negotiation
    Packaging Details: Standard Carton Packing
    Delivery Time: 15 Days
    Payment Terms: T/T
    Supply Ability: 3000 Sheets Month
    Contact Now
    Detailed Product Description
    Materials: Polyurethane Color: Green
    Size: 750*500* 1000*500* Density: 1.20
    Hardness: 80-85 Thickness: 35mm 50mm 75mm 100mm
    High Light:

    machinable foam blocks

    ,

    urethane tooling board

    MB5112  Polyurethane Epoxy Tooling Block Size 750mm - 500mm 1000mm-500mm



    DESCRIPTION





    LiHongTooling Board is especially noteworthy for its smooth and homogeneous surface combined with an even cell structure. It has a high edge stability, small thermal expansion coefficient, low dust formation when being machined, no known physiological effects and odeurs or smell. The range consists of 15 different types, varying in density between 600 - 1300 kg m3. There are 20 different dimensions to a maximum of 1500x500 mm and thicknesses of up to 100 mm are available. Larger blocks can be achieved when bonding several blocks to eachother.



    PolyurethaneTooling board, the toughness, environmental protection, hardness, size stability, temperature tolerance, physical properties such as compressive strength, bending strength is quite good.

    We are quietly supporting these industries, automobiles, high-speed rail, shipbuilding, aviation, ceramics, foundry industry and daily necessities manufacturing and related industrieschecking fixtures, mold, wind power and yacht . Maybe we are also suitable for your product, can try, may have unexpected harvest.





    USES



    1. Design studies

    2. CNC program proving/testing.

    3. Building Landscapes/Features in architectural and scenario models

    4. Forming a mould tool for prototyping short runs of composite parts.

    5. Use for jigs, fixtures, foundry patterns, core boxes.vacuum forming molds and all kinds of models.





    Description
    Density:(g/cm³): 1.20
    Hardness(Shore D): 82
    Compressive Strength(N/mm²): 90
    Temperature Resistance(°C): 80
    Coefficient of Thermal Expansion: 48
    Flexural Strength(N/mm²): 60.5
    Tensile Strength(N/mm²): 30.2
    Dimension(mm)







    (L*W)1000*500*50/75/100

    (L*W)750*500*50/75/100
