| Place of Origin: | China |
| Brand Name: | LH-tool® |
| Certification: | ISO9001:2008 Standard |
| Model Number: | MB5166 |
| Minimum Order Quantity: | 10 Sheets |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Standard Carton Packing |
| Delivery Time: | 15 Days |
| Payment Terms: | T/T |
| Supply Ability: | 3000 Sheets Month |
| Materials: | Polyurethane | Color: | Beige |
|---|---|---|---|
| Size: | 750*500* 1000*500* | Density: | 1.66 |
| Hardness: | 85-90 | Thickness: | 35mm 50mm 75mm 100mm |
| High Light: | foam board for model making,cnc tooling board |
||
35-240mm High Thickness Epoxy PU Tooling Board For Sheet Metal Forming
| Resin tooling board | |||
| Physical performance | Testing standard | MB5166 | |
| Thermal expansivity (1/K) | ISO11359-1 | 43 x 10-6 | |
| Heat distortion temperature (℃) | (ISO 75)℃ | 80-90 | |
| Hardness(Shore D) | (ISO 868)Shore D | 87 | |
| Compressive strength(N/mm2) | (ISO 604)Mpa | 100-110 | |
| bending strength(N/mm2) | (ISO 178)Mpa | 90 | _ |
| Density(g/cm3) | (ISO 1183)g/cm3 | 1.70 | |
| Color | Make as request | BEIGE | |
KEY PROPERTIES
1.Very dense surface structure,can be polished
2.Easily machined
3.Good temperature resistance
4.Very good compressive strength
5.Processing and No dust
6) Good heat resistance
7) High impact and good edge strength
8) Low coefficient of termal expansion
USE
1) Checking fixtures for metal parts
2) Models and molds for polyester applications
3) Models and molds for composites applications
4) Tooling jigs
5) Vacuum forming tools
6) Sheet metal forming
7)Vacuum forming
8) Car fixture
