Machineable Coloured Modelling Paste For Manufacturing Tools / Patterns

Machineable Coloured Modelling Paste For Manufacturing Tools / Patterns

    • Machineable Coloured Modelling Paste For Manufacturing Tools / Patterns
  • Machineable Coloured Modelling Paste For Manufacturing Tools / Patterns

    Product Details:

    Place of Origin: China
    Brand Name: LH-tool®
    Certification: ISO9001:2008 Standard
    Model Number: LH5200 AB

    Payment & Shipping Terms:

    Minimum Order Quantity: 200kgs
    Price: Negotiation
    Packaging Details: Standard Carton Packing
    Delivery Time: 15 Days
    Payment Terms: T/T
    Supply Ability: 30 Tons per Month
    Contact Now
    Detailed Product Description
    Materials: Epoxy Resin Color: Brown
    Package: 10kg 15kg 20kg Density: 0.7-0.8
    Hardness: 60-70 Mixing Ratio: 1 More Than 1
    High Light:

    molding paste


    coloured modelling paste

    Master Models Tooling Paste Epoxy Resin Materials Packing 10kg 15kg 20kgs
    Product main properties
    This product is a two-component materials, by automatically output device fast coating model, single coating thickness can be up to 40 mm, reaction put the quantity of heat low, coating and processing when no smell, room temperature curing can be carried out after a day of machining, machining performance is good, good surface effect, material size stability is good


    Product application
    1. Wind-power blades can be applied to the model of the male die, the cabin cover mould, automobile master model of casting mould board, checking fixture production, foundry industry, sand core boxes, and various modeling tools etc.
    2. used for sheet metal forming mould, tensile modulus, rolling zhong mold, mold, and the bending modulus.
    3. used for foaming mould, vacuum forming mould, injection mould, composite materials forming mould, etc
    4. quick samples/hand: for small batch production of plastic material.
    Product operation process
    Given according to the proportion of fully mixing thoroughly, the same color. Try to avoid to produce bubbles, it is best to use vacuum mixer mixing. Strict control, with a thick layer of a coating is not more than 40 mm;If upset, after waiting for curing the second floor. The after curing processing, performance is better. (after curing: 80 ℃ + 8 h or 3 days) at room temperature, curing can be after rough machining, precision work after 3 days;The material of metal, composite structure materials such as sticky relay is extremely strong, mold release agents shall be used for rolling over. Make sure the strength of the support frame, stability and cleanness, machine

    Descriptionepoxy resincuring agent
    mixing ration11
    mixed time:500g,25°(min)  30
    curing time before machining(20-25mm) (hours)  6-8
    layer thickness (mm)  max.40
    Density:(g/cm³):  0.7-0.8
    Hardness(Shore D):  65-70
    Temperature Resistance(°C):  70-75
    Coefficient of Thermal Expansion(10-6 K-1):  45-50
    Compressive Strength(N/mm²):  16.2
    Flexural Strength(N/mm²):  19.2
    Tensile Strength(N/mm²):  12.4

    easily shaped and machined,fine surface structure
    yacht model,benchmark model, system and sand-cast model, rapid prototype,etc.
