length xwidth 1000*500 Hardness 85 High Density Polyurethane Board
Product Details
| Materials: | Polyurethane | Color: | Beige |
|---|---|---|---|
| Size: | 750*500* 1000*500* 1500*500^ | Density: | 1.70 |
| Hardness: | 85-90 | Thickness: | 35mm 50mm 75mm 100mm |
| Highlight |
cnc Polyurethane Board,1000*500 Polyurethane tooling Board |
||
Product Description
length xwidth 1000*500 Hardness 85 High Density Polyurethane Board
High quality Resin tooling board used for mould on the CNC machine
We are manufacturer of Resin Wood/ CNC Tooling Boards are used to make sole mould pattern, Automobile Designs on the CNC machine. Our product is high quality with very competitive in China. If you are interesed in it, just feel free to contact us any time, we can send the free samples for you!
| Resin tooling board | |||
| Physical performance | Testing standard | 5166 | |
| Thermal expansivity (1/K) | ISO11359-1 | 44 x 10-6 | |
| Heat distortion temperature (℃) | (ISO 75)℃ | 110 | |
| Hardness(Shore D) | (ISO 868)Shore D | 89 | |
| Compressive strength(N/mm2) | (ISO 604)Mpa | 120 | |
| bending strength(N/mm2) | (ISO 178)Mpa | 80 | |
| Density(g/cm3) | (ISO 1183)g/cm3 | 1.7 | |
| Color | Make as request | Pink/ Brown/ white/ yellow | |
| Sheet size (mm) | Also can make the special size as the customer request | 680×430×30/50/75/100 | |
| 690×440×30/50/75/100 | |||
| 700×450×30/50/75/100 | |||
| 700×500×30/50/75/100 | |||
| 750×500×30/50/75/100 | |||
| 1000×500×30/50/75/100 | |||
| 1500×500×50/75/100 | |||
KEY PROPERTIES
1. Good styrene resistance
2. High compressive modulus
3. Good amine resistance
4. Very good compressive strength
5. Processing and No dust
6) Good abrasion resistance
7) Resistant to dry ice cleaning
USE
1. Checking fixtures for metal par
2. Models and molds for polyester applications
3. Models and molds for composites applications
4. Hammer tools
5. Vacuum forming tools
6. Foundry models
7. Foundry pattern plates and core boxes
8. Car fixture
