1.60g/Cm3 Epoxy Tooling Board 75mm Thickness High Density Model Board
Product Details
| Materials: | Polyurethane | Color: | Ivory |
|---|---|---|---|
| Size: | 750x500,1000x500 | Density: | 1.60 |
| Hardness: | 85-90 | Thickness: | 35mm 50mm 75mm 100mm |
| Highlight |
1.60g/Cm3 Epoxy Tooling Board,75mm Thickness Epoxy Tooling Board,Epoxy High Density Model Board |
||
Product Description
1.60g/Cm3 polyurethane Ivory Tooling Board For Die for Die for sheet metal forming
LH-TOOL WB-1600
High-tech polyurethane boards
· The color is ivory white
· Density 1.6g /cm3
· Resistant to high temperature to 100 ºC
· First-rate surface reduces the need for finishing
· Compatible with all paints, release agents and epoxy prepregs that meet industry standards
Working board (WB)
The LH® TOOL workboard combines excellent quality with outstanding mechanical properties.
Semi-finished products -- prefabricated rectangular panels -- are made in epoxy or polyurethane and can be bonded into a variety of shapes and sizes.
The LH® TOOL adhesive matches the hardness and color of the board.
The LH® TOOL work board has a density range of 0.69 to 1.7 g/cm3, providing excellent dimensional stability and easy and fast machining.
Technical parameter
| Style | LH-TOOL WB-1600 |
| Color | Ivory |
| Density(ISO 1183) g/cm3 | 1.60 |
| Applications | 1. Metal plate forming mold 2. Check fixtures 3: Jig |
| Key Properties | 1. Fine surfaces 2. Easy to process 3. Low coefficient of thermal expansion 4. Very good compressive strength |
| Hardness(ISO868)Shore D |
85-90 |
|
Coefficient of thermal expansion
(ISO11359)10-6K-1 |
45-50 |
|
Deflection temperature
(ISO 75) °C |
75-80 |
|
Compressive strength
(ISO 604) MPa |
90-100 |
|
Flexural strength
(ISO 178) MPa |
55-65 |
| Size mm | 750 x 500 x 50 mm 750 x 500 x 75 mm 750 x 500 x 100 mm |
